Magnetic Limit Switch

PreviousApplication ExamplesNextSpecifications

Last updated 11 months ago

Was this helpful?

The REV Robotics Magnetic Limit Switch () is a three-sided digital hall effect switch. The three internal hall effect elements (one on top, two on the sides) are connected in parallel so if any one of them is triggered the sensor will report as triggered.

Hall effect sensors detect the presence of a magnetic fields. The REV Magnetic Limit Switch is an omnipolar momentary switch; it will trigger when there is sufficient field strength of either magnetic pole detected.

Kit Contents

Part Number

Description

Qty

REV Magnetic Limit Switch

1

-

Magnet with mounting tabs

2

JST PH 4-pin Sensor Cable - 30cm

1

REV-31-1462
REV-31-1407
REV-31-1462
